Capacity | 55 lt/min |
Suction/Discharge Size | 3/4" |
Main Body | Polypropylene-Polypropylene Black-PVDF |
Diaphragms | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
Ball Valves | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
Ball Seats | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
Air Inlet Size | 1/4" |
Solids-Handling | 3mm |
Suction Depth | 6m |
Operating Pressure (Max.) | 7 bar |
Delivery Height (Max.) | 70 m |
Operation Temperature | -18 / + 1000C |
