| Capacity | 16 lt/min |
| Suction/Discharge Size | 1/4" |
| Main Body | Polypropylene-PVDF |
| Diaphragms | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
| Ball Valves | Santoprene-Neoprene-BUNA-N-EPDM-Teflon-Viton |
| Ball Seats | Santoprene-Teflon |
| Air Inlet Size | 1/4" |
| Solids-Handling | 1mm |
| Suction Depth | 1m-1,5m |
| Operating Pressure (Max.) | 7 bar |
| Delivery Height (Max.) | 70 m |
| Operation Temperature | -18 / + 1000C |
