  Products > Methalic Body Pumps > VP15 Methalic Body

Capacity 400 lt/dk
Intake/Dıscharge siz 1 1/2"
Main Body Aluminium-Cast iron-Cast Stainless Steel-Sheet Metal(hygienic)
Diaphragms Santoprene-Neoprene-Buna'N-EPDM-Teflon-Viton
Ball Valvese Santoprene-Neoprene-Buna'N-EPDM-Teflon-Viton
Ball Seats Santoprene-Neoprene-Buna'N-EPDM-Teflon-Viton
Air İnlet Size 3/4"
Solids-Handling 6m
Suction Depth 6m
Operating Pressure (Max.) 7 bar
Delivery Height (Max.) 70 m
Operation Temperature -18 / + 1000C
